Zoom-in: JWT

Log in, call an API, server lets you through. This is the auth mechanism AI generates thousands of times a day without explaining why it works.

graph LR
    C(["👤 Client"]) -->|"token"| S(["🖥️ Server"])
    S -->|"200 OK"| C
    style C fill:#1e293b,stroke:#475569,color:#cbd5e1
    style S fill:#1e293b,stroke:#475569,color:#cbd5e1

Zoom in on the black box.

---

Layer 1 — The root problem: server doesn't remember

HTTP is stateless — every request is independent, the server has no memory of the previous one. A user just logged in, but the next request arrives with no context of who's asking.

sequenceDiagram
    participant C as Client
    participant S as Server

    C->>S: POST /login (email + password)
    S-->>C: OK, but server forgets immediately after

    C->>S: GET /dashboard
    S-->>C: Who are you? 401 Unauthorized

Something needs to let the client "prove identity" in every request — without resending the password each time.

---

Layer 2 — Traditional sessions: server remembers for the client

The classic solution: after login, the server creates a random session ID, stores it in a database, then sends it back to the client via cookie.

sequenceDiagram
    participant C as Client
    participant S as Server
    participant DB as Database

    C->>S: POST /login
    S->>DB: Store session {id: "abc123", user_id: 42}
    S-->>C: Set-Cookie: session=abc123

    C->>S: GET /dashboard (Cookie: session=abc123)
    S->>DB: Look up session "abc123"
    DB-->>S: {user_id: 42}
    S-->>C: 200 OK — data for user 42

Works well — but every request requires a database query to validate the session. With multiple servers (horizontal scaling), every server needs access to the same session store.

---

Layer 3 — JWT: the self-contained token

JWT flips the approach: instead of the server storing state, the token carries its own information and proves its own validity.

A JWT has 3 parts separated by .:

eyJhbGciOiJIUzI1NiJ9.eyJ1c2VyX2lkIjo0MiwiZXhwIjoxNzUwMDAwMDAwfQ.xK9mF2...
    HEADER                          PAYLOAD                        SIGNATURE

Anyone can Base64-decode the header and payload to read the content. What protects the token isn't encryption — it's the signature.

---

Layer 4 — The signature: why it can't be forged

The server signs the token with a secret key — a random string only the server knows:

signature = HMAC-SHA256(base64(header) + "." + base64(payload), SECRET_KEY)

When receiving a token, the server recalculates the signature from the header and payload, then compares it with the one in the token:

graph TD
    Req["GET /dashboard\nAuthorization: Bearer eyJ..."] --> Split["Split token\nheader | payload | signature"]
    Split --> Recalc["Recalculate:\nHMAC(header + payload, SECRET_KEY)"]
    Recalc --> Compare{"Compare\nsignatures"}
    Compare -->|"Match + not expired"| OK["200 OK — user_id=42"]
    Compare -->|"Mismatch / expired"| Fail["401 Unauthorized"]

    style Req fill:#1e3a5f,stroke:#3b82f6,color:#93c5fd
    style Split fill:#3b2a1a,stroke:#f59e0b,color:#fcd34d
    style Recalc fill:#3b2a1a,stroke:#f59e0b,color:#fcd34d
    style Compare fill:#3b2a1a,stroke:#f59e0b,color:#fcd34d
    style OK fill:#1a3a2a,stroke:#22c55e,color:#86efac
    style Fail fill:#3b1a1a,stroke:#ef4444,color:#fca5a5

If someone modifies the payload (e.g., changes user_id from 42 to 1), the signature won't match — because they don't have the SECRET_KEY to re-sign it. The server rejects it immediately.

---

Full picture

From cookie/session to stateless JWT.

graph TD
    Login["POST /login\nemail + password"] --> Verify["Verify\ncredentials"]
    Verify --> Sign["Sign JWT\nHMAC(header+payload, SECRET)"]
    Sign --> Client["Client\nstores token"]

    Client --> Req["GET /dashboard\nBearer eyJ..."]
    Req --> Check["Server verifies\nrecalculates signature"]

    Check -->|"Match + not expired"| Allow["200 OK"]
    Check -->|"Mismatch / expired"| Deny["401 Unauthorized"]

    style Login fill:#1e3a5f,stroke:#3b82f6,color:#93c5fd
    style Client fill:#1e3a5f,stroke:#3b82f6,color:#93c5fd
    style Req fill:#1e3a5f,stroke:#3b82f6,color:#93c5fd
    style Verify fill:#3b2a1a,stroke:#f59e0b,color:#fcd34d
    style Sign fill:#3b2a1a,stroke:#f59e0b,color:#fcd34d
    style Check fill:#3b2a1a,stroke:#f59e0b,color:#fcd34d
    style Allow fill:#1a3a2a,stroke:#22c55e,color:#86efac
    style Deny fill:#3b1a1a,stroke:#ef4444,color:#fca5a5

---

Three common misconceptions

Takeaway

JWT exists to solve the centralized session store problem — not to be more secure than session cookies. The HMAC signature ensures the token can't be forged; Base64 doesn't hide the data. Stateless has a price: tokens can't be revoked, so short expiry and refresh tokens are mandatory.

When debugging auth, the right question: "did the token expire, was it tampered with, or was it correctly rejected?" — exp, the signature, and the 401 vs 403 distinction will point to which layer has the problem.

---
